Product performance

Model power voltage current speed flow exhaust pressure noise

Weight outline dimension

2.2KW 380V/50HZ 9.3A 1440RPM 420L/min 0-10bar 65dB RS50-4VS

70kg 865 * 540 * 855mm

220V/50HZ 2.2KW

420L/min 18A

0-10bar

< 65dB

70kg

865 * 540 * 855mm

Three, product features

Advantages and characteristics of solar eclipse without oil air compressor:

1, the unit is no oil unit, easy to use, without refueling, maintenance is simple, low power consumption, low cost.

2, the unit and the traditional oil air compressor, vibration, low noise, gas clean and environmental protection, the appearance of the machine clean and tidy.

3, multi unit combined work, gas production is large, the upper air, exhaust gas flow and pressure stable and sustained, to meet the requirements of long time.

4, the unit by the whole intelligent automatic control, safe, convenient and reliable.

5, intelligent controller has the following functions:

A. directly shows the voltage, current and other parameters of each unit's operation;

B. on the motor with precise overload display protection function;

C. when a large amount of gas, the need for continuous gas supply, with a pump head rotation work function;

The current is too large to start up and shutdown function in D..

The intelligent controller has the following functions:

A, with an uninterrupted gas supply capacity, B, intelligent constant pressure control,

C, intelligent voltage regulation function, D, intelligent remote control function,

E, with low pressure air supply function, F, unit intelligent delay function,

G, lack of phase protection. Application range

Performance characteristics:

1 Germany imported technology, the maximum pressure of up to 2.0Mpa

2 double cylinder balance compression, small vibration, low noise, the balance of the host

3 using the Swedish SKF high pressure bearing and Germany PEEP high wear resistant sealing material

4 microcomputer control, automatic fault diagnosis, automatic memory, automatic display

5 timing can be open, shut down, any adjustment of the compressor start and stop pressure

6 microcomputer using non contact design, continuous action can be more than one hundred thousand times

7 anti-corrosion treatment to ensure air quality, no pollution, no impurities.

8 exhaust port on the air forced filtration, to ensure that the air moisture content is less than 0.01ppm, dust content of less than 0.01

9 the whole machine is made of stainless steel pipe and the service life is five years.

Application range

Application of oil free air compressor, which are widely used in any medical, laboratory, water treatment, pharmaceutical, environmental protection, shipbuilding, petrochemical, textile, electronics, precision instruments, spraying, tobacco, nitrogen, * * processing, optics, national defense and scientific research need to clean compressed air field.

Four, service system

Suggestion on selection of silent air compressor without oil

Silent air compressor is a leader in air compressor, in the premise of losing lubricating oil to ensure the good operation of the compressor is the first condition is high temperature, friction.

Silent air compressor without oil temperature must be above 360 degrees Celsius, test pressure must be achieved using the pressure of more than 2 times before it can guarantee the normal operation of the compressor during the warranty period. For example: the actual use of 8bar air compressor, in product selection when it is to choose the test pressure in the 16bar of the compressor as a standard. This is also the manufacturer's production standards: high pressure design, high pressure test, low voltage use. So as to ensure that you choose the quality of worry.

According to the actual situation of the oil free air compressor, the starting pressure has a very important influence on the noise, vibration and the service life of the main engine. Therefore, it is very important to set up the most suitable starting and stopping pressure difference. General control between 1bar-1.5bar is appropriate. For example, the medical and instrument industry, start and stop the pressure is set to 4.5bar-6.0bar for the best. The noise and vibration of the compressor is reduced by at least 30%, and the service life of the machine is prolonged by more than 2 times.

Selection of microcomputer control, high security, to avoid the occurrence of leakage accidents, more important is the adjustment of the pressure and the diagnosis of air compressor failure at a glance.

The selection of air compressor and the air storage tank, not the bigger the better, as long as can satisfy the law as 1:5:2.

Select manufacturer. The biggest advantage of the manufacturer to the customer is the support of the technology selection, and can be designed according to the actual working condition of the customer. How to determine whether the manufacturer's direct standard is a business license on the obvious signs. No production capacity of the manufacturers are labeled 'sales', manufacturers are marked' production and processing '.

How to judge the noise and quality of the oil free air compressor. The sealing performance of the oil free air compressor is the potential standard to determine the noise and quality. How to test: the use of 2 times the pressure to test the various indicators of air compressor.

The German air compressor test standard: 15bar pressure; durability test (destructive testing) mark: continuous operation time must be more than 5000 hours (minutes non-stop); impact test must reach above 5 T and 10T; salt spray test: 200 hours

Silent oil free air compressor service policy

(a), our company to implement the machine warranty for two years, the host warranty for five years, and the whole machine to implement a lifetime maintenance. The host in the warranty period, if your company needs the maintenance of compressor, our company in as far as possible to ensure that your company needs uninterrupted gas supply situation, for your company's air pressure equipment maintenance.

(two), our company is responsible for free start-up, commissioning and operation of the operator's on-site training. Our company provides free technical training in the factory. The length of training time and determined by the buyer (I may provide a reference scheme).

(three), our company will be installed in the equipment, send a rich experience of the engineers to the site to carry out technical services, free of charge for debugging and
