(specific parameters or in kind to the contract agreement shall prevail)

Oil free air compressor (L Series)

Silent type less than 55 dB

power

2200 W

Voltage

110v/220v/380v

Maximum output pressure

10bar (150psi)

Maximum flow

90L/min

Adapt to ambient temperature

-50 degrees Celsius to 60

Endurance test

5000 hours

Service life

10 years

control mode

PLC

drying system

Matching

Drainage of gas storage tank

Manual / automatic (optional)

Basic outline dimensions

400*400*650mm (specific size to type selection)

Matching capacity of gas storage tank

50L/90L/120L

Product configuration

Host import / accessories made in China

Implementation standards

CE GB

Advantages and characteristics of oil free silent air compressor

First, the machine itself material does not contain oily substances, work do not add any lubricating oil, thus greatly improving the exhaust air quality, the user to complete the safety of equipment has also been protected, unlike oil air compressor, containing large oil molecules in exhaust gas, will bring to the user equipment matching different degree of corrosion, so no guarantee of oil air compressor on the air quality is necessary.

Secondly, the use of silent oil free air compressor is also more convenient and simple to maintain the oil air compressor. As everyone knows, some regular machine replacement or gas compressor oil use, and some have the opportunity to air pressure injection, leakage and pollution to the surrounding environment is also used in different degree, requiring the user to spend time cleaning, it will increase the relative user workload, which in turn with people using machine in order to improve the work efficiency of the equipment will violate. Compared with the air compressor, is basically not users spend time to maintain oil free air compressor, because it does not add a drop of oil, automatic pressure switch will be based on your use of gas the automatic start or stop, is saving peace of mind. The drainage device automation for users to worry a lot, so it is very convenient to use. Life is longer than the oil silent type air compressor!

Performance characteristics:

1 Germany imported technology, the maximum pressure of up to 2.0Mpa

2 double cylinder balance compression, small vibration, low noise, the balance of the host

3 using the Swedish SKF high pressure bearing and Germany PEEP high wear resistant sealing material

4 microcomputer control, automatic fault diagnosis, automatic memory, automatic display

5 timing can be open, shut down, any adjustment of the compressor start and stop pressure

6 microcomputer using non contact design, continuous action can be more than one hundred thousand times

7 anti-corrosion treatment to ensure air quality, no pollution, no impurities.

8 exhaust port on the air forced filtration, to ensure that the air moisture content is less than 0.01ppm, dust content of less than 0.01

9 the whole machine is made of stainless steel pipe and the service life is five years.

Application range

Application of oil free air compressor, which are widely used in any medical, laboratory, water treatment, pharmaceutical, environmental protection, and * * * *, shipbuilding, petrochemical, textile, electronics, precision instruments, spraying, tobacco, nitrogen, * * processing, optics, national defense and scientific research need to clean compressed air field.

Suggestion on selection of silent air compressor without oil

Silent air compressor is a leader in air compressor, in the premise of losing lubricating oil to ensure the good operation of the compressor is the first condition is high temperature, friction.

Silent air compressor without oil temperature must be above 360 degrees Celsius, test pressure must be achieved using the pressure of more than 2 times before it can guarantee the normal operation of the compressor during the warranty period. For example: the actual use of 8bar air compressor, in product selection when it is to choose the test pressure in the 16bar of the compressor as a standard. This is also the manufacturer's production standards: high pressure design, high pressure test, low voltage use. So as to ensure that you choose the quality of worry.

According to the actual situation of the oil free air compressor, the starting pressure has a very important influence on the noise, vibration and the service life of the main engine. Therefore, it is very important to set up the most suitable starting and stopping pressure difference. General control between 1bar-1.5bar is appropriate. For example, the medical and instrument industry, start and stop the pressure is set to 4.5bar-6.0bar for the best. The noise and vibration of the compressor is reduced by at least 30%, and the service life of the machine is prolonged by more than 2 times.

Selection of microcomputer control, high security, to avoid the occurrence of leakage accidents, more important is the adjustment of the pressure and the diagnosis of air compressor failure at a glance.

The selection of air compressor and the air storage tank, not the bigger the better, as long as can satisfy the law as 1:5:2.

Select manufacturer. The biggest advantage of the manufacturer to the customer is the support of the technology selection, and can be designed according to the actual working condition of the customer. How to determine whether the manufacturer's direct standard is a business license on the obvious signs. No production capacity of the manufacturers are labeled 'sales', manufacturers are marked' production and processing '.

How to judge the noise and quality of the oil free air compressor. The sealing performance of the oil free air compressor is the potential standard to determine the noise and quality. How to test: the use of 2 times the pressure to test the various indicators of air compressor.

The German air compressor test standard: 15bar pressure; durability test (destructive testing) mark: continuous operation time must be more than 5000 hours (minutes non-stop); impact test must reach above 5 T and 10T; salt spray test: 200 hours

Silent oil free air compressor service policy

(a), our company to implement the machine warranty for two years, the host warranty for five years, and the whole machine to implement a lifetime maintenance. Host after the warranty period, if your company needs to maintain the compression of the host, I am in the company
